Legrand Plexo push-button — 6A, 250V, 2 poles, Grey — 090462
Reference: 090462
Manufacturer image associated with this reference.
At a glance
The Legrand 090462 is a push-button in the Plexo range. Configuration: 6A, 250V, 2 poles, Grey.
- Range
- Plexo
- Rated current (In)
- 6A
- Rated voltage
- 250V
- Number of poles
- 2
Price, packaging and lead time confirmed for your quantity and destination.
View my selection and send the enquiry ↗The product in detail
The Legrand 090462 is a push-button in the Plexo range. Configuration: 6A, 250V, 2 poles, Grey.
Technical characteristics: Rated current (In): 6A; Rated voltage: 250V; Number of poles: 2; IK impact rating: IK08; Colour: Grey; Material: Plastic; Mounting method: Surface-mounted; Number of modules: 2.
For wiring accessories exposed to moisture or dust, check the IP rating and mounting conditions of the complete assembly. Specify the reference, cable entries and compatible accessories to suit the installation environment.
For a quotation, specify reference 090462, quantity and delivery country. MWB TRADING confirms availability and the accessories needed for your project.
Applications
- Weatherproof wiring accessories
For a tailored quotation
For wiring accessories exposed to moisture or dust, check the IP rating and mounting conditions of the complete assembly. Specify the reference, cable entries and compatible accessories to suit the installation environment.
Contact our team ↗Specifications
| Brand | Legrand |
|---|---|
| Reference | 090462 |
| Range | Plexo |
| Rated current (In) | 6A |
| Rated voltage | 250V |
| Number of poles | 2 |
| IK impact rating | IK08 |
| Colour | Grey |
| Material | Plastic |
| Mounting method | Surface-mounted |
| Number of modules | 2 |
| Connection type | Screw terminal |
| Material grade | Thermoplastic |
| Halogen-free | Yes |
| Antimicrobial treatment | No |
| Surface finish | Matt |
| Equivalent RAL number | 7016 |
| Transparent | No |
| Suitable IP protection rating | IP66 |
| Device width | 98mm |
| Device height | 117mm |
| Device depth | 63mm |
| Minimum back-box depth | 40mm |
| Apple HomeKit compatible | No |
| Google Assistant compatible | No |
| Amazon Alexa compatible | No |
| IFTTT compatible | No |
| EAN/GTIN | 3245060904623 |
